Astronomy 161: An Introduction to Solar System Astronomy Prof. Richard Pogge, MTWThF 2:30

Lecture 8: The Phases of the Moon

Key Ideas:

• Rotation and Revolution are synchronous.

• Fraction of the sunlit side visible to us.

• Lunar Sidereal Period: 27.3 days
• Lunar Synodic Period: 29.5 days

Our Nearest Celestial Neighbor

Its orbit around the Earth is elliptical:

• ~0.15% out of circular.
• Tilted by 5° from the Ecliptic.
• Mean Distance: 384,400 km
• Perigee (Closest Approach): 363,300 km
• Apogee (Maximum Distance): 405,500 km
• Appears ~11% larger at Perigee than at Apogee

Synchronous Rotation

• The Moon completes 1 rotation about its axis in the same time as it completes 1 orbit around the Earth.

As a consequence, the Moon always keeps the same face towards the Earth.

• Near Side: hemisphere facing towards the Earth
• Far Side: hemisphere facing away from the Earth

The synchronization of the Moon's rotation and orbit is caused by strong tidal forces from the Earth that effectively "locks" the Moon's orientation relative to the Earth.

[Note: The degree of synchronization is not perfect for two reasons. First, the Moon's orbit is elliptical rather than circular, so that the Moon's orbital speed is faster at perigee and slower at apogee. This mis-match in the exact orbital and rotation rates results in an apparent east-west "rocking" motion of the Moon by about 7.9 degress over the course of a month. The second is that the axis of the moon's rotation is tilted by about 7 degrees relative to its orbital plane (like the Earth's 23.5 degrees). This leads to an additional north-south nodding motion over the course of a month. The combined rocking and nodding motion motion is called "libration". You can see libration in the lunation movie below.]

Phases of the Moon

• It shines only by reflected sunlight
• Surface is very dark, only ~7% reflective

During the month, we see a complete cycle of Phases:

• The sunward hemisphere is fully lit.
• The opposite hemisphere is dark.

The phase of the Moon depends on the fraction of the sunlit hemisphere visible to us.

Graphical depiction of the phases (click to see full-size)

New Moon & Full Moon

• Moon and Sun are on the same side of the sky.
• Near side is in total darkness.
• Moon and Sun rise together.

Full Moon:

• Moon is opposite the Sun in the sky.
• The near side is fully illuminated.
• Moon rises as the Sun is setting.

Quarter Moon

• Half of the near side is illuminated
• Half of the far side is illuminated

First Quarter:

• Quarter Moon between New Moon and Full Moon.

Last Quarter:

• Quarter Moon between Full Moon and New Moon.
• Sometimes also called "Third Quarter"

With New Moon and Full Moon, they help to divide the Lunar Month into quarters.

Waxing & Waning

• Waxing Crescent: just after New Moon
• Waxing Gibbous: just before Full Moon

Waning: decreasing illumination

• Waning Gibbous: just after Full Moon
• Waning Crescent: just before New Moon

Moonrise, Moonset...

• Never see a crescent moon at midnight.
• Never see the last quarter moon at sunset.
• Never see a full moon during the day.

Times of rising and setting depend on the details of the Earth-Sun-Moon configuration as viewed from the surface of the rotating Earth.

Moonrise and Moonset during Full Moon:

(Click on the image to view at full scale [Size: 28Kb])

• Full Moon rises as the Sun sets.
• The Full Moon is in mid-sky at Midnight.
• Full Moon sets as the Sun rises.
• Full Moon cannot be seen during the day.

The View from the Moon

Answer:

• See the Earth neither rise nor set, but stay nearly fixed at the same position in the sky.
• See the Earth rotate on its axis once every 24^h.
• See the Earth go through phases.

Lunar Sidereal Period

• Moon's Sidereal period = 27.3 days
• Also called the "Sidereal Month"

The Sidereal Period of the moon is measured watching its motions against the background stars:

The Moon on 1999 Oct 2: Last Quarter Moon in Gemini

27.3 days later on 1999 Oct 29: Waning Gibbous Moon in Gemini

Note: The background constellation is the same 27 days later (Gemini), but the Moon is in a different, earlier phase (Waning Gibbous, which comes before Last Quarter phase).

Lunar Synodic Period

• Moon's Synodic period = 29.5 days
• Also called the "Synodic Month"

This is the month used by Lunar Calendars:

• The Islamic calendar starts and ends on the New Moon, signaled by the first appearance of the Waxing Crescent moon.

Why are they different?

• Start at New Moon: Sun-Moon-Earth aligned.
• It takes the Moon 27.3 days to complete 1 orbit around Earth with respect to the stars.
• In the meantime, the Earth has moved through 27.3 days of its orbit (about 27deg along its orbit).
• The Moon & Earth must move together for an extra 2.2 days to re-align with the Sun.

Sidereal is derived from the Latin word for star (sidus). A Sidereal Period denotes the time it takes for an object (for example, the Moon) to return to the same place as seen with respect to the stars.

Synodic is derived from the Greek word synodos, meaning a "coming together" (e.g., a Church "Synod"). The Synodic Period of the Moon is therefore the time between the apparent coming together of the Sun and Moon on the same side of the sky at successive New Moons.

Synodic periods always require you to combine two Sidereal periods. In this case, we are combining the orbit of the Moon around the Earth (the Moon's Sidereal Period), and the Earth's orbit around the Sun (the Earth's Sidereal Period) together to compute the Synodic Period.
