Introduction to Stars, Galaxies, & the Universe
Prof. Richard Pogge, MTWThF 9:30
Lecture 3: Matter & Light
Readings: Chapter 5, sections 5-3 & 5-4
Temperature (Kelvin Scale)
Kirchoff's Laws of Spectroscopy
- Measures internal energy content.
Continuous (Blackbody) Spectrum
Emission-and Absorption-Line Spectra
Each atom has a unique spectral signature
- Stefan-Boltzmann Law
- Wien Law
The Interaction of Light & Matter
Light & Matter can interact in a number of different ways:
The last two (absorption and emission) bear on the internal
energy of the matter.
- Matter can transmit light (glass, water).
- Matter can reflect light.
- Matter can gain energy by absorbing light.
- Matter can lose energy by emitting light.
Temperature is a measurement of the internal energy content of an
- Higher temperature means higher average vibrational
energy per atom or molecule.
- Higher temperature means more average kinetic energy
(faster speeds) per atom or molecule.
Kelvin Temperature Scale
An absolute temperature system:
- Developed by Lord Kelvin (19th century)
- Uses the Celsius temperature scale.
Absolute Kelvin Scale (K):
- 0 K = Absolute Zero
- 273 K = pure water freezes (0º Celsius)
- 373 K = pure water boils (100º C)
The principal advantage of the Kelvin scale compared to the more
familiar Celsius and Fahrenheit scales is that the temperature measured
in Kelvins is directly proportional to the amount of internal energy in
an object. If you double the internal energy, you double the
temperature in Kelvins. This is why the Kelvin scale is said to measure
absolute temperature. Both the Celsius and Fahrenheit systems
are difficult to use for relating the absolute energy content of objects
because they are tied arbitrarily to the freezing and boiling points of
water on the surface of the Earth.
We will primarily use the Kelvin scale in this course.
Kirchoff's Laws of Spectroscopy
- A hot solid or hot, dense gas produces a continuous
- A hot, low-density gas produces an emission-line
- A continuous spectrum source viewed through a cool,
low-density gas produces an absorption-line
Gustav Kirchoff formulated these laws empirically in the mid-19th
century. While they adequately describe the different kinds of spectra
that are observed, they do not explain why these spectra appear
in these circumstances. It was not until the early 20th century, with
the development of quantum mechanics to explain the nature of the atom,
when we fully understood the origins of spectra.
Energy emitted per second per area by a blackbody with
s is Boltzmann's constant (a
"Hotter objects are Brighter
at All Wavelengths"
Relates the wavelength of maximum emission by a blackbody to its
- "Hotter objects are BLUER"
- "Cooler objects are REDDER"
Heating a bar of Iron
Use a torch to heat an iron bar from 300K (room temperature) up to 600K.
The net result of heating any blackbody is that
- Temperature increases by a factor of 2
- Brightness increases by 24=16 times (Stefan-Boltzman Law)
- Peak wavelength shifts towards the blue by a factor of 2 from
about 10-microns in the mid-infrared to 5-microns.
- Gets brighter at all wavelengths
- Gets bluer in color
Person: Body Temperature = 310 K
Sun: Surface Temperature = 5770 K
In Astronomy 162, we will use the properties of blackbodies, via the
Stefan-Boltzman and Wien Laws, to help us understand some of the observed
properties of stars.
Hydrogen: The Simplest Atom
An atom of Hydrogen (1H) consists of:
- A single proton in the nucleus.
- A single electron orbiting the nucleus.
First orbital: Ground State (n=1)
- Lowest energy orbital the electron can reside in.
Higher orbitals: Excited States (n=2,3,...)
- Higher orbits around the nucleus.
- Come at specific, exact energies.
(Click on the image to view at full scale [Size: 8Kb])
Emission & Absorption Lines
When an electron jumps from a higher to a lower energy
orbital, a single photon is emitted with exactly the
energy difference between orbitals. No more, no less.
(Click on the image to view at full scale [Size: 19Kb])
Electrons can get into the excited states by either
- Colliding with other atoms or free electrons
- Absorbing photons of specific energies...
When an electron absorbs a photon with exactly the
energy needed to jump from a lower to a higher orbital.
(Click on the image to view at full scale [Size: 51Kb])
Absorption is very specific:
The excited states decay by emitting photons in random directions.
- Only photons with the exact excitation energy are absorbed.
- All others pass through unabsorbed.
Other atoms have more electrons, and hence more complex
electron orbital structures.
- Results in more complex line spectra.
- There is a unique spectrum for each element, reflecting
its unique electron orbital structure.
- Isotopes show the same lines, but slightly shifted in
Every element has its own, distinctive spectral signature.
The Importance of Spectroscopy
From the emission or absorption lines in an object's spectrum, we can
learn many things of importance, especially:
These data can give us a nearly complete picture of the physical
conditions in the object, even though that object is separated from
us by vast, unbridgable cosmic distances.
- Composition: Which elements are present and in what proportions
- Which elements are ionized (missing or extra electrons) in whole or in part
- Which molecules are present
- The temperature, pressure, and density of the gas
Spectroscopy is what transformed Astronomy into Astrophysics.
